35M Eco-friendly Camouflaged Maple Tree Bionic Tower Hot Dip Galvanized 4G 5G Wifi Long Range Communication Signal Mast

Name: 35M Eco-friendly Camouflaged Maple Tree Bionic Tower Hot Dip Galvanized 4G 5G Wifi Long Range Communication Signal Mast
Brand: Jiayao Co., Ltd.
SKU: Tour d'arbre bionique
Price: 50.00 USD
Availability: InStock

Tous les produits

Tour en acier angulaire à 3 pattes
(48)

Tour en acier angulaire à 4 pattes
(61)

Tour en acier tubulaire à trois pattes
(45)

Tour du monopole
(53)

Tour de fil de fer
(26)

Tour de garde
(15)

Tour d'arbre bionique
(25)

Tour de transmission électrique
(18)

Je suis en ligne une discussion en ligne

35M Eco-friendly Camouflaged Maple Tree Bionic Tower Hot Dip Galvanized 4G 5G Wifi Long Range Communication Signal Mast

Image Grand : 35M Eco-friendly Camouflaged Maple Tree Bionic Tower Hot Dip Galvanized 4G 5G Wifi Long Range Communication Signal Mast

Détails sur le produit:

Lieu d'origine:	Chine
Nom de marque:	Jiayao
Certification:	ISO9001:2008 COC
Numéro de modèle:	Tour d'arbre bionique

Conditions de paiement et expédition:

Quantité de commande min:	4 tonnes
Prix:	US$1600,1-100Tons;US$1000,>=100 Tons
Détails d'emballage:	Emballés dans des boîtes en bois ou en carton galvanisé
Délai de livraison:	15-20 jours
Conditions de paiement:	LC, T/T
Capacité d'approvisionnement:	500 à 800 tonnes par mois

Contact Causez Maintenant

35M Eco-friendly Camouflaged Maple Tree Bionic Tower Hot Dip Galvanized 4G 5G Wifi Long Range Communication Signal Mast

description de

Matériel:	Q345b	Certificat:	ISO9001 : 2008
Nom du produit:	Tour bionique en érable camouflé écologique	Hauteur:	10-80m
Vitesse du vent:	1-42 KM/H	Durée de vie:	15-50 ans
Impact environnemental:	Respectueux de l'environnement	Esthétique:	Une apparence naturelle et réaliste
Caractéristiques de sécurité:	Anti-corrosion, anti-rouille et anti-éclairage
Mettre en évidence:	Eco-friendly bionic tree tower , Galvanized 4G 5G signal mast , Long range communication tower

JIAYAO CO., LTD.

1.Specifications

Design
1. Design Code	ANSI/TIA-222-G/H/F
Structure Steel
2. Grade	Mild Steel	High Tensile Steel
	GB/T 700:Q235B, Q235C,Q235D	GB/T1591:Q355B, Q355C,Q355D
	ASTM A36	ASTM A572 Gr50
	EN10025: S235JR, S235J0,S235J2	EN10025: S355JR, S355J0,S355J2
3. Design Wind Speed	Up to 250 km/h
4. Allowable deflection	0.5 ~1.0 degree @ operational speed
5. Tension strength (Mpa)	360~510	470~630
6. Yield strength (t≤16mm) (Mpa)	355	235
7. Elongation (%)	20	24
8. Impact strength KV (J)	27(20°C)---Q235B(S235JR)	27(20°C)---Q345B(S355JR)
	27(0°C)---Q235C(S235J0)	27(0°C)---Q345C(S355J0)
	27(-20°C)---Q235D(S235J2)	27(-20°C)---Q345D(S355J2)
Bolts & Nuts
9. Grade	Grade 4.8, 6.8, 8.8
10. Standards for mechanical properties
10.1 Bolts	ISO 898-1
10.2 Nuts	ISO 898-2
10.3 Washers	ISO 6507-1
11. Standards for Dimensions
11.1 Bolts	DIN7990, DIN931, DIN933
11.2 Nuts	ISO4032, ISO4034
11.3 Washers	DIN7989, DIN127B, ISO7091
Welding
12. Method	CO2 Shielded Arc Welding & Submerged Arc Welding(SAW)
13. Standard	ISO9001:2008 COC
Marking
14. Method of marking of the members	Hydraulic Press Stamping
Galvanizing
15. Galvanization standard of steel sections	ISO 1461 or ASTM A123
16. Galvanization standard of bolts and nuts	ISO 1461 or ASTM A153

2.Product Detail

Please Click Here For More Information!!!!!!

3.Packaging & Shipping

4.Cooperation Customers

5.Certifications

6.Our Services

JIAYAO CO., LTD. is a professional telecom tower manufacturer and approved by ISO9001. We are committed to providing customers with the most optimized solutions and the best communication tower. Many products have been exported to USA, Europe and other 55 different counties.
We specialize in designing and manufacturer of angle steel tower, tube steel tower, monopole tower, pine tree tower, guyed tower and guard tower. Our departments include design, R&D, inspection, laboratory, QC, galvanization and steel tower departments. Our raw materials come from famous steel mills in China: HBIS Group, Baowu Steel Group, Shougang Group.

If you need it, we will welcome you 24 hours a day!

Design
1. Design Code	ANSI/TIA-222-G/H/F, EN 1991-1-4 & EN 1993-3-1
Structure Steel
2. Grade	Mild Steel
	GB/T 700:Q235B, Q235C,Q235D
	ASTM A36
	EN10025: S235JR, S235J0,S235J2
3. Design Wind Speed	Up to 250 km/h
4. Allowable deflection	0.5 ~1.0 degree @ operational speed
5. Tension strength (Mpa)	360~510
6. Yield strength (t≤16mm) (Mpa)	355
7. Elongation (%)	20
8. Impact strength KV (J)	27(20°C)---Q235B(S235JR)
	27(0°C)---Q235C(S235J0)
	27(-20°C)---Q235D(S235J2)
Bolts & Nuts
9. Grade	Grade 4.8, 6.8, 8.8
10. Standards for mechanical properties
10.1 Bolts	ISO 898-1
10.2 Nuts	ISO 898-2
10.3 Washers	ISO 6507-1
11. Standards for Dimensions
11.1 Bolts	DIN7990, DIN931, DIN933
11.2 Nuts	ISO4032, ISO4034
11.3 Washers	DIN7989, DIN127B, ISO7091
Welding
12. Method	CO2 Shielded Arc Welding & Submerged Arc Welding(SAW)
13. Standard	AWS D1.1
Marking
14. Method of marking of the members	Hydraulic Press Stamping
Galvanizing
15. Galvanization standard of steel sections	ISO 1461 or ASTM A123
16. Galvanization standard of bolts and nuts	ISO 1461 or ASTM A153
